序号	型号	频率GHz	饱和功率(dB,Typ.)	增益(dB,Typ.)	电压(V)	输入端口	输出端口
1	FAP000011-31	0.1-11	30	28	15	2.92mm(f)	2.92mm(f)
2	FAP000020-20	0.1-20	20	15	15	2.92mm(f)	2.92mm(f)
3	FAP001018-20	1-18	20	20	12	SMA(f)	SMA(f)
4	FAP018040-17	18-40	17	20	12	2.92mm(f)	2.92mm(f)
5	FAP018040-23	18-40	23	17	5	2.92mm(f)	2.92mm(f)
6	FAP018040-24	18-40	24	27	12	2.92mm(f)	2.92mm(f)
7	FAP018040-29	18-40	29	20	12	2.92mm(f)	2.92mm(f)
8	FAP026040-20	26-40	20	20	12	2.92mm(f)	2.92mm(f)
9	FAP026040-23	26-40	23	17	5	2.92mm(f)	2.92mm(f)
10	FAP026040-27	26-40	27	20	12	2.92mm(f)	2.92mm(f)
11	FAP027045-19	27-45	19	18	12	2.4mm(f)	2.4mm(f)
12	FAP027045-21	27-45	21	21	8-12	2.4mm(f)	WR23-UG383
13	FAP027045-24	27-45	24	23	12	2.4mm(f)	2.4mm(f)
14	FAP027045-26	27-45	26	22	12	2.4mm(f)	2.4mm(f)
15	FAP027045-29	27-45	29	20	12	2.4mm(f)	2.4mm(f)
16	FAP027050-21	27-50	21	24	8-12	2.4mm(f)	WR23-UG383
17	FAP033050-17	33-50	17	15	12	WR22-UG383	WR22-UG383
18	FAP033050-20	33-50	20	16	12	WR22-UG383	WR22-UG383
19	FAP033060-21	33-60	19	17	12	WR19-UG383	WR19-UG383
20	FAP040060-17	40-60	17	14	12	WR19-UG383	WR19-UG383
21	FAP040060-20	40-60	20	17	12	WR19-UG383	WR19-UG383
22	FAP050060-26	50-60	26	15	12	WR19-UG383	WR19-UG383
23	FAP050060-29	50-60	29	15	12	WR19-UG383	WR19-UG383
24	FAP050075-17	50-75	17	16	12	WR15-UG387/UM	WR15-UG387/UM
25	FAP050075B-29	50-75	29	15	16	WR15-UG387/UM	WR15-UG387/UM
26	FAP052072-27	52-72	27	12.5	12	WR15-UG387/UM	WR15-UG387/UM
27	FAP055085-20	55-85	20	15	12	WR12-UG387/UM	WR12-UG387/UM
28	FAP071076-23	71-76	23	15	12	WR12-UG387/UM	WR12-UG387/UM
29	FAP071076-26	71-76	26	15	12	WR12-UG387/UM	WR12-UG387/UM
30	FAP071076-29	71-76	29	15	12	WR12-UG387/UM	WR12-UG387/UM
31	FAP071086-23	71-86	23	15	12	WR12-UG387/UM	WR12-UG387/UM
32	FAP071086-26	71-86	26	15	12	WR12-UG387/UM	WR12-UG387/UM
33	FAP071086-29	71-86	29	14	12	WR12-UG387/UM	WR12-UG387/UM
34	FAP060090-17	60-90	17	15	12	WR12-UG387/UM	WR12-UG387/UM
35	FAP060090-20	60-90	20	13	12	WR12-UG387/UM	WR12-UG387/UM
36	FAP081086B-27	81-86	27	19	12	WR10-UG387/UM	WR10-UG387/UM
37	FAP082088A-25	82-88	25	13	12	WR10-UG387/UM	WR10-UG387/UM
38	FAP080090-23	80-90	23	15	12	WR10-UG387/UM	WR10-UG387/UM
39	FAP080090-26	80-90	26	14	12	WR10-UG387/UM	WR10-UG387/UM
40	FAP080090-29	80-90	29	14	12	WR10-UG387/UM	WR10-UG387/UM
41	FAP090100-23	90-100	23	15	12	WR10-UG387/UM	WR10-UG387/UM
42	FAP090100-26	90-100	26	13	12	WR10-UG387/UM	WR10-UG387/UM
43	FAP090100-29	90-100	29	10	12	WR10-UG387/UM	WR10-UG387/UM
44	FAP075110-17	75-110	17	15	12	WR10-UG387/UM	WR10-UG387/UM
45	FAP075110-20	75-110	20	15	12	WR10-UG387/UM	WR10-UG387/UM
46	FAP075110-22	75-110	22	15	12	WR10-UG387/UM	WR10-UG387/UM
47	FAP080130-18	80-130	18	13	12	WR9-UG387/UM	WR9-UG387/UM
48	FAP080130-21	80-130	21	13	12	WR8-UG387/UM	WR8-UG387/UM
49	FAP180220-13	180-220	13	13	12	WR4.3-UG387/UM	WR4.3-UG387/UM
50	FAP195220-10	195-220	10	16	12	WR4.3-UG387/UM	WR4.3-UG387/UM
51	FAP195220-17	195-220	17	17	12	WR4.3-UG387/UM	WR4.3-UG387/UM
52	FAP210230-12	210-230	12	19	12	WR4.3-UG387/UM	WR4.3-UG387/UM
53	FAP200220-15	200-220	14.5	8	12	WR4.3-UG387/UM	WR4.3-UG387/UM
