    TiS60+ 320 x 240高分辨率手持红外热像仪|福禄克 (在产)

    Boost your team’s performance with 320 x 240 resolution. Infrared images taken with the TiS60+ capture smaller temperature differences from farther away. If you are new to thermal imaging or if your camera is being used by a team 。
    参考价格 ：

    厂家：福禄克|Fluke Corporation （收录272个产品）

    产地：美国

    点击访问厂家官网

    产品描述
    详细指标
    软件和手册|白皮书
    购买渠道
    选件
    问大家
    视频
    测评
    口碑
    系统与解决方案

    Fluke Corporation · 红外热像仪

    TiS60+ 高分辨率手持红外热像仪

    1.86 mRad, D:S 532:1 · 320 x 240 (76, 800 pixels) · 34.1 °H x 25.6 °H · Fixed
    1.86 mRad, D:S 532:1
    IFOV (spatial resolution)
    320 x 240 (76, 800 pixels)
    Infrared resolution
    34.1 °H x 25.6 °H
    Field of view
    Fixed
    Focus system
    46 cm (18 in)
    Minimum focus distance
    Yes (both value and table)
    On-screen emissivity correction
    产品定位

    Boost your team’s performance with 320 x 240 resolution. Infrared images taken with the TiS60+ capture smaller temperature differences from farther away. If you are new to thermal imaging or if your camera is being used by a team with varying levels of thermal imaging experience,

    the TiS60+ offers fixed focus with the ability to capture quality images from farther.

    The TiS60+ allows you to see things that are invisible to the eye and reveal problems that cannot be detected with other technologies. It is a simple to use,

    dependable thermal camera that the team can rely on.

    核心参数
    Key features
    · IFOV (spatial resolution)：1.86 mRad, D:S 532:1
    · Infrared resolution：320 x 240 (76, 800 pixels)
    · Field of view：34.1 °H x 25.6 °H
    · Focus system：Fixed
    · Minimum focus distance：46 cm (18 in)
    · Ruggedized display：3.5 inch (8.9 cm landscape) 320 x 240 LCD
    · Ergonomic design：Designed for one-handed use
    Temperature measurement
    · Temperature range (not calibrated below -10 °C)：-20 °C to 400 °C (-4 °F to 752 °F)
    功能与特点
    · 320 x 240 resolution
    · 2 meter drop test
    · IR Fusion technology for context
    · Measure up to 400 °C
    · Subject to Export Control
    典型应用
    · 电气设备检测
    资源下载
    · 本页仅列出核心参数，完整技术指标请见 tis60plus-specs.html
    Fluke Corporation · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。





    Fluke Corporation · 红外热像仪

    TiS60+ 高分辨率手持红外热像仪 · 详细指标

    1.86 mRad, D:S 532:1 · 320 x 240 (76, 800 pixels) · 34.1 °H x 25.6 °H · Fixed
    产品简介

    Boost your team’s performance with 320 x 240 resolution. Infrared images taken with the TiS60+ capture smaller temperature differences from farther away. If you are new to thermal imaging or if your camera is being used by a team with varying levels of thermal imaging experience,

    the TiS60+ offers fixed focus with the ability to capture quality images from farther.

    完整技术指标
    Key features
    · IFOV (spatial resolution)：1.86 mRad, D:S 532:1
    · Infrared resolution：320 x 240 (76, 800 pixels)
    · Field of view：34.1 °H x 25.6 °H
    · Focus system：Fixed
    · Minimum focus distance：46 cm (18 in)
    · Ruggedized display：3.5 inch (8.9 cm landscape) 320 x 240 LCD
    · Ergonomic design：Designed for one-handed use
    Temperature measurement
    · Temperature range (not calibrated below -10 °C)：-20 °C to 400 °C (-4 °F to 752 °F)
    · Accuracy
    – ± 2 °C or 2 % (at 25 °C nominal, whichever is greater)
    · Thermal sensitivity (NETD)：≤ 0.045 °C at 30 °C target temp (45 mK)
    · On-screen emissivity correction：Yes (both value and table)
    · On-screen reflected background temperature compensation：Yes
    · On-screen transmission correction：No
    Wireless connectivity
    · Wireless connectivity
    – Yes, to PC, iPhone and iPad (iOS 4s and later), Android 4.3 and up, and WiFi and LAN (where available)
    · Fluke Connect app compatible
    – Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing
    · Fluke Connect Assets optional software
    – Yes*, assign images to assets and create work orders. Easily compare measurement types - whether mechanical, electrical or infrared images - in one location
    IR Fusion technology
    · IR Fusion technology：Yes
    · AutoBlend mode：Yes
    · Picture-In-Picture (PIP)：Yes
    · Built-in digital camera (visible light)：5MP
    Level and span
    · Fast auto-rescale in manual mode：Yes
    · Minimum span (in manual mode)：2.5 °C (4.5 °F)
    · Minimum span (in auto mode)：5 °C (9.0 °F)
    Data storage and image capture
    · Image capture, review, save mechanism
    – One-handed image capture, review, and save capability
    · Image file formats
    – Non-radiometric BMP or JPEG or fully-radiometric is2
    · Memory review：Yes
    · Software
    – Fluke Connect desktop software - full analysis and reporting software with access to the Fluke Connect system
    · Analyze and store radiometric data on a PC：Yes
    · Export file formats with Fluke Connect software：is2, BMP, GIF, JPEG, PNG, TIFF
    · Voice annotation
    – 60 seconds maximum recording time per image
    – reviewable playback on camera
    – Bluetooth headset required (sold separately)
    · IR-PhotoNotes：Yes - 3 images
    · Auto capture (temperature and interval)：Yes
    电池
    · Battery life：4 hours continuous use per battery pack
    · Battery charging time：2.5 hours to full charge
    · Battery charging system
    – Two-bay battery charger or in-imager charging. Optional 12 V automotive charging adapter
    · AC operation
    – AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz)
    · Power saving：User selectable
    Color palettes
    · Ultra contrast palettes
    – 8: Ironbow Ultra, Blue-Red Ultra, High Contrast Ultra, Amber Ultra, Hot Metal Ultra, Grayscale Ultra, Grayscale Inverted Ultra
    一般规格
    · Laser pointer：Yes
    · Frame rate：< 9 Hz or 30 Hz
    · Infrared spectral band：7.5 μm to 14 μm
    · Operating temperature：-10 °C to +50 °C (14 °F to 122 °F)
    · Storage temperature
    – -20 °C to +50 °C (-4 °F to 122 °F) without batteries
    · Relative humidity：10 % to 95 %, non-condensing
    · Center-point temperature measurement：Yes
    · Spot temperature：Hot and cold spot markers
    · User-definable spot markers：3
    · User defined measurement boxes：Expandable-contractible measurement box
    · Hard case
    – Rugged hard carrying case with soft transport bag, including adjustable strap
    · Safety standards
    – IEC 61010-1: Overvoltage category II, Pollution Degree 2
    · Electromagnetic compatibility
    – IEC 61326-1: Basic EM environment. CISPR 11: Group 1, Class A
    · Australian RCM：RCM IEC 61326-1
    · US FCC
    – EN61326-1; FCC Part 5, EN 55011: Class A, EN 61000-4-2, EN 61000-4-3
    · Vibration：2G, IEC 68-2-6
    · Shock：25G, IEC 68-2-29
    · Drop
    – Engineered to withstand 2 meter (6.5 feet) drop
    · Sized (H x W x L)
    – 26.7 cm x 10.1 cm x 14.5 cm (10.5 in x 4.0 in x 5.7 in)
    · Weight (battery included)：0.72 kg (1.6 lb.)
    · Enclosure rating
    – IP54 (protected against dust, limited ingress; protection against water spray from all directions)
    · Warranty：Two-years (standard)
    · Recommended calibration cycle
    – Two-years (assumes normal operation and normal aging)
    · Supported languages
    – Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
    · RoHS compliant：Yes
    以上指标摘自厂商官方网站产品页/公开技术资料；厂商未标注测试条件与典型值口径的条目均按原文收录，实际以厂商正式规格书为准。
    资源下载
    Fluke Corporation · onetest 仪器资源库
    本文由 onetest 仪器资源库依据厂商公开资料整理，参数以厂商正式资料为准。
